| BRAND | J+J Automation |
| Product | P/N: S4C010109, Type: J4C-S20 |
| Description | Electric drive with DPS positioning system |
| Internal code | IMP4064156 |
| Custom code | 85437090 |
| Technical specification | F03/F04/F05 *14mm DPS 4-20mA NC • DPS positioning system 4-20mA NC • Input and output signal • 2x SPST NO silver contact (5A 125VAC/3A 250VAC) and 2 path limit switches Working torque: 20 Nm/Breakaway torque: 25 Nm Swivel angle: 0°-90° (freely adjustable) Supply voltage: S= 24-240V DC/AC (50/60Hz) Brushless motor with long life, 75% ED Mount (ISO5211): F03/F04/F05 *14mm double square Ambient temperature: -20°C/+70°C Protection class: IP67, robust PA6 plastic housing Plug: 4-pin valve plug type A/CI |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for J+J Automation - P/N: S4C010109, Type: J4C-S20 Electric drive with DPS positioning system number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
IMG_20230322_083149.jpg | |
|
|
IMG_20230627_151023.jpg | |
|
|
WIN_20230912_08_26_49_Pro.jpg | |
|
|
WIN_20231004_10_49_40_Pro.jpg | |
|
|
WIN_20240521_16_15_49_Pro.jpg | |
|
|
20240528_154434.jpg |
