| BRAND | Jesco |
| Product | 10241016 ( MAGDOS LD 1 PP/FPM ) |
| Description | Pump |
| Internal code | IMP3828046 |
| Weight | 3.2 |
| Custom code | 84135040 |
| Technical specification | Solenoid Diaphragm Dosing Pump Mathcode: 0102D0010BP011A2K2KP1ZP1Z0 Solenoid-Diaphragm Dosing Pump Product: MAGDOS Type: LD Delivery rate: 0.76 l/h at 16 bar - 1.1 l/h at 8 bar Capacity adjustment: Stroke frequency adjustable: up to 250 strokes/min Material dosing head and valves: PP Control unit: 230 V AC, 50/60 Hz Electrical connection: 1.8 m mains cable with plug, Europe (for 230 V AC) Suction valve DN3: Double-ball ceramic/PVDF/FPM (ball/seat/gasket) Discharge Valve DN3: Double-ball ceramic/PVDF/FPM (ball/seat/gasket) Material suction connection: PP Suction connection: Hose clamp connection set 4/6, 6/9 and 6/12 Material discharge connection: PP Discharge connection: Hose clamp connection set 4/6, 6/9 and 6/12 Dosing head arrangement: Floor mounting Functions Stroke frequency can be precisely adjusted via the keyboard Graphic display Pulse input (increase and reduction) with connection cable Level input with early warning and main alarm Release input for external start/stop |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Jesco - 10241016 ( MAGDOS LD 1 PP/FPM ) Pump number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
